DC-DC Преобразователи
| Фото | Номер производителя | Наличие | Цена | Количество | Технический лист | Серия | Корпус/корпус | Упаковка | Состояние продукта | Тип | Количество выходов | Напряжение - вход (мин.) | Напряжение - вход (макс.) | Напряжение - выход 1 | Напряжение - Выход 2 | Напряжение - Выход 3 | Напряжение - Выход 4 | Ток - выход (макс.) | Мощность (Вт) | Напряжение - Изоляция | Применение | Особенности | Рабочая температура | Эффективность | Марка | Квалификация | Тип крепления | Размер/измерение | Устройство поставщика Упаковка | Функции управления | Сертифицирующее агентство | Стандартный номер |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PT6472NDC DC CONVERTER 2.5V 14A |
0 | - |
|
Технический лист |
Excalibur™ PT6470 | 12-SIP Module | Tray | Obsolete | Non-Isolated PoL Module | 1 | 2.95V | 3.65V | 2.5V | - | - | - | 14A | - | - | ITE (Commercial) | - | -40°C ~ 85°C | 93% | - | - | Through Hole | 1.71" L x 0.48" W x 0.68" H (43.4mm x 12.2mm x 17.3mm) | - | - | - | - |
|
ZUW1R54812DC DC CONVERTER +/-12V |
30 | - |
|
Технический лист |
ZUW (1.5W) | 5-DIP Module | Box | Obsolete | Isolated Module | 2 | 36V | 72V | 12V | -12V | - | - | 65mA, 65mA | - | 500 V | ITE (Commercial) | OCP | -20°C ~ 71°C (With Derating) | 71% | - | - | Through Hole | 1.08" L x 0.71" W x 0.28" H (27.5mm x 18.0mm x 7.0mm) | - | - | - | - |
|
ZUS1R51215DC DC CONVERTER 15V |
16 | - |
|
Технический лист |
ZUS (1.5W) | 4-DIP Module | Box | Obsolete | Isolated Module | 1 | 9V | 18V | 15V | - | - | - | 100mA | - | 500 V | ITE (Commercial) | OCP | -20°C ~ 71°C (With Derating) | 71% | - | - | Through Hole | 1.08" L x 0.71" W x 0.28" H (27.5mm x 18.0mm x 7.0mm) | - | - | - | - |
|
PYBE10-Q24-D12DC DC CONVERTER +/-12V 10W |
9 | - |
|
Технический лист |
PYBE10 (10W) | 24-DIP Module, 9 Leads | Tube | Not For New Designs | Isolated Module | 2 | 9V | 36V | 12V | -12V | - | - | 416mA, 416mA | 10 W | 1.5 kV | ITE (Commercial) | Remote On/Off, OCP, OVP, SCP | -40°C ~ 85°C (With Derating) | 87% | - | - | Through Hole | 1.26" L x 0.79" W x 0.43" H (32.0mm x 20.0mm x 10.8mm) | - | - | EN | 55024; 55032 Class A |
|
NES1000N30S05DC DC CONVERTER 0.75-5.5V |
38 | - |
|
Технический лист |
NES | - | Tray | Active | Non-Isolated PoL Module | 1 | 8.5V | 18V | 0.75 ~ 5.5V | - | - | - | 30A | - | - | ITE (Commercial) | Adjustable Output, Remote On/Off, Remote Sense | -40°C ~ 85°C | 96% | - | - | Surface Mount | 1.30" L x 0.53" W x 0.32" H (33.0mm x 13.5mm x 8.1mm) | - | Enable, Active Low | cURus | - |
|
URB2405JD-15WDC DC CONVERTER 5V 15W |
38 | - |
|
Технический лист |
URB2405JD-15W (15W) | 14-DIP Module | Tray | Not For New Designs | Isolated Module | 1 | 9V | 36V | 5V | - | - | - | 3A | 15 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 88% | - | - | Through Hole | 1.52" L x 1.07" W x 0.24" H (38.7mm x 27.2mm x 6.2mm) | - | - | CE | 62368-1 |
|
|
URB2415JD-15WDC DC CONVERTER 15V 15W |
27 | - |
|
Технический лист |
URB2415JD-15W (15W) | 14-DIP Module | Tray | Not For New Designs | Isolated Module | 1 | 9V | 36V | 15V | - | - | - | 1A | 15 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 89% | - | - | Through Hole | 1.52" L x 1.07" W x 0.23" H (38.7mm x 27.2mm x 5.8mm) | - | - | CE | 62368-1 |
|
URB4805JT-15WDC DC CONVERTER 5V 15W |
18 | - |
|
Технический лист |
URB4805JT-15W (15W) | 15-SMD Module | Tray | Not For New Designs | Isolated Module | 1 | 18V | 75V | 5V | - | - | - | 3A | 15 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 88% | - | - | Surface Mount | 1.52" L x 1.07" W x 0.24" H (38.7mm x 27.2mm x 6.2mm) | - | - | CE, UKCA | 62368-1 |
|
|
URB4812JT-15WDC DC CONVERTER 12V 15W |
9 | - |
|
Технический лист |
URB4812JT-15W (15W) | 15-SMD Module | Tray | Not For New Designs | Isolated Module | 1 | 18V | 75V | 12V | - | - | - | 1.25A | 15 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 89% | - | - | Surface Mount | 1.52" L x 1.07" W x 0.23" H (38.7mm x 27.2mm x 5.8mm) | - | - | CE, UKCA | 62368-1 |
|
|
URB4815JD-15WDC DC CONVERTER 15V 15W |
9 | - |
|
Технический лист |
URB4815JD-15W (15W) | 14-DIP Module | Tray | Not For New Designs | Isolated Module | 1 | 18V | 75V | 15V | - | - | - | 1A | 15 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 89% | - | - | Through Hole | 1.52" L x 1.07" W x 0.23" H (38.7mm x 27.2mm x 5.8mm) | - | - | CE | 62368-1 |
|
|
URB4815JT-15WDC DC CONVERTER 15V 15W |
9 | - |
|
Технический лист |
URB4815JT-15W (15W) | 15-SMD Module | Tray | Not For New Designs | Isolated Module | 1 | 18V | 75V | 15V | - | - | - | 1A | 15 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 89% | - | - | Surface Mount | 1.52" L x 1.07" W x 0.23" H (38.7mm x 27.2mm x 5.8mm) | - | - | CE, UKCA | 62368-1 |
|
|
URB4803JD-15WDC DC CONVERTER 3.3V 15W |
9 | - |
|
Технический лист |
URB4803JD-15W (15W) | 14-DIP Module | Tray | Not For New Designs | Isolated Module | 1 | 18V | 75V | 3.3V | - | - | - | 4.5A | 15 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 88% | - | - | Through Hole | 1.52" L x 1.07" W x 0.24" H (38.7mm x 27.2mm x 6.2mm) | - | - | CE | 62368-1 |
|
|
URB4803JT-15WDC DC CONVERTER 3.3V 15W |
9 | - |
|
Технический лист |
URB4803JT-15W (15W) | 15-SMD Module | Tray | Not For New Designs | Isolated Module | 1 | 18V | 75V | 3.3V | - | - | - | 4.5A | 15 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 88% | - | - | Surface Mount | 1.52" L x 1.07" W x 0.24" H (38.7mm x 27.2mm x 6.2mm) | - | - | CE, UKCA | 62368-1 |
|
|
URB2412JD-15WDC DC CONVERTER 12V 15W |
9 | - |
|
Технический лист |
URB2412JD-15W (15W) | 14-DIP Module | Tray | Not For New Designs | Isolated Module | 1 | 9V | 36V | 12V | - | - | - | 1.25A | 15 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 89% | - | - | Through Hole | 1.52" L x 1.07" W x 0.23" H (38.7mm x 27.2mm x 5.8mm) | - | - | CE | 62368-1 |
|
|
URB2415JT-15WDC DC CONVERTER 15V 15W |
9 | - |
|
Технический лист |
URB2415JT-15W (15W) | 15-SMD Module | Tray | Not For New Designs | Isolated Module | 1 | 9V | 36V | 15V | - | - | - | 1A | 15 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 89% | - | - | Surface Mount | 1.52" L x 1.07" W x 0.23" H (38.7mm x 27.2mm x 5.8mm) | - | - | CE, UKCA | 62368-1 |
|
|
URB2403JD-15WDC DC CONVERTER 3.3V 15W |
9 | - |
|
Технический лист |
URB2403JD-15W (15W) | 14-DIP Module | Tray | Not For New Designs | Isolated Module | 1 | 9V | 36V | 3.3V | - | - | - | 4.5A | 15 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 88% | - | - | Through Hole | 1.52" L x 1.07" W x 0.24" H (38.7mm x 27.2mm x 6.2mm) | - | - | CE | 62368-1 |
|
|
URB2403JT-15WDC DC CONVERTER 3.3V 15W |
9 | - |
|
Технический лист |
URB2403JT-15W (15W) | 15-SMD Module | Tray | Not For New Designs | Isolated Module | 1 | 9V | 36V | 3.3V | - | - | - | 4.5A | 15 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 88% | - | - | Surface Mount | 1.52" L x 1.07" W x 0.24" H (38.7mm x 27.2mm x 6.2mm) | - | - | CE, UKCA | 62368-1 |
|
|
URB2412JT-15WDC DC CONVERTER 12V 15W |
7 | - |
|
Технический лист |
URB2412JT-15W (15W) | 15-SMD Module | Tray | Not For New Designs | Isolated Module | 1 | 9V | 36V | 12V | - | - | - | 1.25A | 15 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 89% | - | - | Surface Mount | 1.52" L x 1.07" W x 0.23" H (38.7mm x 27.2mm x 5.8mm) | - | - | CE, UKCA | 62368-1 |
|
REC5-0512DRW/H/BDC DC CONVERTER +/-12V 5W |
60 | - |
|
Технический лист |
ECONOLINE REC5 (5W) | 24-DIP Module, 12 Leads | Tube | Active | Isolated Module | 2 | 4.5V | 9V | 12V | -12V | - | - | 210mA, 210mA | 5 W | 1.6 kV | ITE (Commercial) | SCP | -40°C ~ 75°C | 75% | - | - | Through Hole | 1.26" L x 0.80" W x 0.40" H (32.0mm x 20.3mm x 10.2mm) | - | - | - | - |
|
REC3-2412DRW/H4/A/SMDDC DC CONVERTER +/-12V 3W |
75 | - |
|
Технический лист |
ECONOLINE REC3-DRW (3W) | 24-SMD Module, 18 Leads | Tube | Active | Isolated Module | 2 | 18V | 36V | 12V | -12V | - | - | 125mA, 125mA | 3 W | 4 kV | ITE (Commercial), Medical | SCP | -40°C ~ 85°C | 85% | - | - | Surface Mount | 1.26" L x 0.78" W x 0.44" H (32.0mm x 19.9mm x 11.2mm) | - | - | - | - |
