DC-DC Преобразователи
| Фото | Номер производителя | Наличие | Цена | Количество | Технический лист | Серия | Корпус/корпус | Упаковка | Состояние продукта | Тип | Количество выходов | Напряжение - вход (мин.) | Напряжение - вход (макс.) | Напряжение - выход 1 | Напряжение - Выход 2 | Напряжение - Выход 3 | Напряжение - Выход 4 | Ток - выход (макс.) | Мощность (Вт) | Напряжение - Изоляция | Применение | Особенности | Рабочая температура | Эффективность | Марка | Квалификация | Тип крепления | Размер/измерение | Устройство поставщика Упаковка | Функции управления | Сертифицирующее агентство | Стандартный номер |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PRQ150W-Q48-S48-DDC DC CONVERTER 48V 150W |
3 | - |
|
Технический лист |
PRQ150W | Quarter Brick | Tray | Not For New Designs | Isolated Module | 1 | 18V | 75V | 48V | - | - | - | 3.13A | 150 W | 2.25 kV | ITE (Commercial) | Adjustable Output, Remote On/Off, Remote Sense | -40°C ~ 85°C (With Derating) | 91% | - | - | Through Hole | 2.43" L x 1.58" W x 0.50" H (61.8mm x 40.2mm x 12.7mm) | Quarter Brick | - | CE | 62368-1 |
|
PTEA404120P2ADDC DC CONVERTER 12V 50W |
24 | - |
|
Технический лист |
PTEA404120 (50W) | 8-DIP Module, 1/8 Brick | Tray | Not For New Designs | Isolated Module | 1 | 35V | 75V | 12V | - | - | - | 4.2A | 50 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 85°C | 91% | - | - | Through Hole | 2.22" L x 0.90" W x 0.52" H (56.4mm x 22.9mm x 13.2mm) | - | - | - | - |
|
RDC4072D12DC DC CONVERTER +/-12V 40W |
8 | - |
|
Технический лист |
RDC (40W) | 6-DIP Module | Tube | Active | Isolated Module | 2 | 36V | 140V | 12V | -12V | - | - | 1.65A, 1.65A | 40 W | 1.5 kV | ITE (Commercial), Railway | Remote On/Off, OCP, OTP, OVP, SCP, UVLO | -40°C ~ 85°C | 87% | - | - | Through Hole | 2.00" L x 1.60" W x 0.42" H (50.8mm x 40.6mm x 10.7mm) | - | Enable, Active High | - | 62368-1 |
|
QAE100-110S24WDC DC CONVERTER 24V 89W |
5 | - |
|
Технический лист |
QAE100W (100W) | Quarter Brick | Box | Active | Isolated Module | 1 | 40V | 160V | 24V | - | - | - | 3.7A | 89 W | 3 kV | ITE (Commercial) | Adjustable Output, Remote On/Off, Remote Sense | -40°C ~ 105°C | 89% | - | - | Through Hole | 2.28" L x 1.45" W x 0.50" H (57.9mm x 36.8mm x 12.7mm) | Quarter Brick | Enable, Active Low | CB, CE, cURus | - |
|
AM25EUW-7224SH30ZKDC DC CONVERTER 24V 25W |
7 | - |
|
Технический лист |
AM25EUW-Z (25W) | - | Tube | Active | Isolated Module | 1 | 16V | 160V | 24V | - | - | - | 1.04A | 25 W | 3 kV | ITE (Commercial) | Heat Sink, Remote On/Off | -40°C ~ 100°C | 85% | - | - | Through Hole | 1.09" L x 2.09" W x 0.65" H (27.6mm x 53.0mm x 16.6mm) | - | - | - | - |
|
AM25EUW-7215SH30ZKDC DC CONVERTER 15V 25W |
2 | - |
|
Технический лист |
AM25EUW-Z (25W) | - | Tube | Active | Isolated Module | 1 | 16V | 160V | 15V | - | - | - | 1.67A | 25 W | 3 kV | ITE (Commercial) | Heat Sink, Remote On/Off | -40°C ~ 100°C | 85% | - | - | Through Hole | 1.09" L x 2.09" W x 0.65" H (27.6mm x 53.0mm x 16.6mm) | - | - | - | - |
|
|
PRQ150W-Q48-S48-H-DDC DC CONVERTER 48V 150W |
10 | - |
|
Технический лист |
PRQ150W | Quarter Brick | Tray | Not For New Designs | Isolated Module | 1 | 18V | 75V | 48V | - | - | - | 3.13A | 150 W | 2.25 kV | ITE (Commercial) | Adjustable Output, Heat Sink, Remote On/Off, Remote Sense | -40°C ~ 85°C (With Derating) | 91% | - | - | Through Hole | 2.43" L x 1.58" W x 1.09" H (61.8mm x 40.2mm x 27.7mm) | Quarter Brick | - | CE | 62368-1 |
|
|
HAE75-110S48WDC DC CONVERTER 48V 77W |
10 | - |
|
Технический лист |
HAE75W (75W) | Half Brick | Box | Active | Isolated Module | 1 | 43V | 160V | 48V | - | - | - | 1.6A | 77 W | 3 kV | ITE (Commercial) | Adjustable Output, Remote On/Off, Remote Sense | -40°C ~ 105°C (With Derating) | 90% | - | - | Through Hole | 2.40" L x 2.28" W x 0.50" H (61.0mm x 57.9mm x 12.7mm) | Half Brick | Enable, Active Low | CB, CE, cURus | - |
|
|
HAE75-110S24WDC DC CONVERTER 24V 77W |
4 | - |
|
Технический лист |
HAE75W (75W) | Half Brick | Box | Active | Isolated Module | 1 | 43V | 160V | 24V | - | - | - | 3.2A | 77 W | 3 kV | ITE (Commercial) | Remote On/Off | -40°C ~ 105°C (With Derating) | 90% | - | - | Through Hole | 2.40" L x 2.28" W x 0.50" H (61.0mm x 57.9mm x 12.7mm) | Half Brick | Enable, Active Low | CB, CE, cURus | - |
|
|
HAE75-110S12WDC DC CONVERTER 12V 76W |
3 | - |
|
Технический лист |
HAE75W (75W) | Half Brick | Box | Active | Isolated Module | 1 | 43V | 160V | 12V | - | - | - | 6.3A | 76 W | 3 kV | ITE (Commercial) | Remote On/Off | -40°C ~ 105°C (With Derating) | 91% | - | - | Through Hole | 2.40" L x 2.28" W x 0.50" H (61.0mm x 57.9mm x 12.7mm) | Half Brick | Enable, Active Low | CB, CE, cURus | - |
|
|
PRQ150W-Q48-S24-B-DDC DC CONVERTER 24V 150W |
17 | - |
|
Технический лист |
PRQ150W | Quarter Brick | Tray | Not For New Designs | Isolated Module | 1 | 18V | 75V | 24V | - | - | - | 6.25A | 150 W | 2.25 kV | ITE (Commercial) | Adjustable Output, Baseplate, Remote On/Off, Remote Sense | -40°C ~ 85°C (With Derating) | 91% | - | - | Through Hole | 2.44" L x 2.20" W x 0.57" H (62.0mm x 56.0mm x 14.6mm) | Quarter Brick | - | CE | 62368-1 |
|
RQB-50Y24DC-DC,14-160V INPUT, 24V/2.08A O |
4 | - |
|
Технический лист |
RQB-50Y (50W) | Quarter Brick | Tray | Active | Isolated Module | 1 | 14V | 160V | 24V | - | - | - | 2.08A | 50 W | 3 kV | ITE (Commercial) | Adjustable Output, Remote On/Off, Remote Sense | -40°C ~ 105°C | 88% | - | - | Through Hole | 2.28" L x 1.45" W x 0.50" H (57.9mm x 36.8mm x 12.7mm) | Quarter Brick | - | cCSAus, CE, UKCA | 62368-1 |
|
RDC3072T0515DC DC CONVERTER 5V +/-15V 30W |
14 | - |
|
Технический лист |
RDC (30W) | 7-DIP Module | Tube | Active | Isolated Module | 3 | 36V | 140V | 5V | 15V | -15V | - | 4A, 330mA, 330mA | 30 W | 1.5 kV | Railway | Remote On/Off, OCP, OVP, SCP, UVLO | -40°C ~ 75°C | 90% | - | - | Through Hole | 2.00" L x 1.00" W x 0.40" H (50.8mm x 25.4mm x 10.2mm) | - | Enable, Active High | - | 62368-1 |
|
HO1-P1201-0.6BDC DC CONVERTER 200-1200V 0.72W |
14 | - |
|
Технический лист |
HO1-P(N)1201-0.6B | 7-DIP Module | Tube | Not For New Designs | Non-Isolated PoL Module | 1 | 4.5V | 5.5V | 1.2V | - | - | - | 600mA | - | - | ITE (Commercial) | Adjustable Output, Remote On/Off | -40°C ~ 85°C | - | - | - | Through Hole | 0.59" L x 0.59" W x 0.71" H (15.0mm x 15.0mm x 18.0mm) | - | - | - | 62368-1 |
|
|
QAE100-110S48WDC DC CONVERTER 48V 86W |
15 | - |
|
Технический лист |
QAE100W (100W) | Quarter Brick | Box | Active | Isolated Module | 1 | 40V | 160V | 48V | - | - | - | 1.8A | 86 W | 3 kV | ITE (Commercial) | Adjustable Output, Baseplate, Remote On/Off, Remote Sense, Standby Output | -40°C ~ 105°C (With Derating) | 89% | - | - | Through Hole | 2.28" L x 1.45" W x 0.50" H (57.9mm x 36.8mm x 12.7mm) | Quarter Brick | Enable, Active Low | CB, CE, cURus | 62368-1 |
|
|
QAE100-110S05WDC DC CONVERTER 5V 85W |
4 | - |
|
Технический лист |
QAE100W (100W) | Quarter Brick | Box | Active | Isolated Module | 1 | 40V | 160V | 5V | - | - | - | 17A | 85 W | 3 kV | ITE (Commercial) | Adjustable Output, Baseplate, Remote On/Off, Remote Sense, Standby Output | -40°C ~ 105°C (With Derating) | 89% | - | - | Through Hole | 2.28" L x 1.45" W x 0.50" H (57.9mm x 36.8mm x 12.7mm) | Quarter Brick | Enable, Active Low | CB, CE, cURus | 62368-1 |
|
|
ODC150-54SC48-WDC/DC 9VDC ~ 75VDC INPUT 8:1 |
5 | - |
|
Технический лист |
ODC150-SC (150W) | Half Brick | Box | Active | Isolated Module | 1 | 9V | 75V | 54V | - | - | - | 2.778A | 150 W | 3 kV | ITE (Commercial) | Adjustable Output, Remote On/Off, Remote Sense | -40°C ~ 105°C (With Derating) | 89% | - | - | Through Hole | 2.40" L x 2.28" W x 0.50" H (61.0mm x 57.9mm x 12.7mm) | Half Brick | - | - | 62368-1 |
|
|
ODC150-12SC48-WUltra wide input VDC 8:1 throu |
3 | - |
|
Технический лист |
ODC150-SC (150W) | Half Brick | Box | Active | Isolated Module | 1 | 9V | 75V | 12V | - | - | - | 12.5A | 150 W | 3 kV | ITE (Commercial) | Adjustable Output, Remote On/Off, Remote Sense | -40°C ~ 105°C (With Derating) | 90% | - | - | Through Hole | 2.40" L x 2.28" W x 0.50" H (61.0mm x 57.9mm x 12.7mm) | Half Brick | - | - | 62368-1 |
|
|
MPQ60-24S12WISOLATED / 60W / VOUT: 12 |
14 | - |
|
Технический лист |
MPQ60W (60W) | Quarter Brick | Box | Active | Isolated Module | 1 | 9V | 36V | 12V | - | - | - | 5A | 60 W | 5 kV | ITE (Commercial), Medical | Adjustable Output | -40°C ~ 105°C (With Derating) | 91.5% | - | - | Through Hole | 2.28" L x 1.45" W x 0.50" H (57.9mm x 36.8mm x 12.7mm) | Quarter Brick | - | CB, CE, cURus, UKCA | 60601-1; 62368-1 |
|
|
MPQ60-24S24WISOLATED / 60W / VOUT: 24 |
8 | - |
|
Технический лист |
MPQ60W (60W) | Quarter Brick | Box | Active | Isolated Module | 1 | 9V | 36V | 24V | - | - | - | 2.5A | 60 W | 5 kV | ITE (Commercial), Medical | Adjustable Output | -40°C ~ 105°C (With Derating) | 90% | - | - | Through Hole | 2.28" L x 1.45" W x 0.50" H (57.9mm x 36.8mm x 12.7mm) | Quarter Brick | - | CB, CE, cURus, UKCA | 60601-1; 62368-1 |
