DC-DC Преобразователи
| Фото | Номер производителя | Наличие | Цена | Количество | Технический лист | Серия | Корпус/корпус | Упаковка | Состояние продукта | Тип | Количество выходов | Напряжение - вход (мин.) | Напряжение - вход (макс.) | Напряжение - выход 1 | Напряжение - Выход 2 | Напряжение - Выход 3 | Напряжение - Выход 4 | Ток - выход (макс.) | Мощность (Вт) | Напряжение - Изоляция | Применение | Особенности | Рабочая температура | Эффективность | Марка | Квалификация | Тип крепления | Размер/измерение | Устройство поставщика Упаковка | Функции управления | Сертифицирующее агентство | Стандартный номер |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
JTD2048S05DC DC CONVERTER 5V 20W |
10 | - |
|
Технический лист |
JTD20 (20W) | 6-DIP Module | Tube | Active | Isolated Module | 1 | 18V | 75V | 5V | - | - | - | 4A | 20 W | 3 kV | ITE (Commercial) | Remote On/Off, OCP, OVP, SCP | -40°C ~ 100°C (With Derating) | 90% | - | - | Through Hole | 1.60" L x 1.00" W x 0.41" H (40.6mm x 25.4mm x 10.4mm) | - | - | CE | 62368-1 |
|
UC10-24D15DC-DC CONVERTER, ISOLATED MODULE |
10 | - |
|
Технический лист |
UC10 (10W) | 16-DIP Module, 6 Leads | Tube | Active | Isolated Module | 2 | 9V | 36V | 15V | -15V | - | - | 333mA, 333mA | 10 W | 1.6 kV | ITE (Commercial) | - | -40°C ~ 77°C | 88% | - | - | Through Hole | 0.94" L x 0.55" W x 0.39" H (24.0mm x 14.0mm x 9.8mm) | - | - | - | - |
|
AXA02C36-LDC DC CONVERTER 15V 25W |
38 | - |
|
Технический лист |
AXA (25W) | 6-DIP Module | Tube | Active | Isolated Module | 1 | 18V | 75V | 15V | - | - | - | 1.67A | 25 W | 1.5 kV | ITE (Commercial) | Remote On/Off, SCP | -40°C ~ 85°C | 90% | - | - | Through Hole | 1.00" L x 1.00" W x 0.40" H (25.4mm x 25.4mm x 10.2mm) | - | - | - | - |
|
|
DDRH-15-15PI/P:150~1500VDC;O/P:15V/0~1A |
18 | - |
|
Технический лист |
DDRH-15 (15W) | 5-DIP Module | Bulk | Active | High Voltage - Isolated Module | 1 | 150V | 1500V | 15V | - | - | - | 1A | 15 W | 4 kV | ITE (Commercial) | - | -40°C ~ 80°C (With Derating) | 87% | - | - | Through Hole | 3.00" L x 2.00" W x 0.98" H (76.2mm x 50.8mm x 25.0mm) | - | - | CE, EAC, UKCA | - |
|
AEE01B24-MDC DC CONVERTER 12V 15W |
14 | - |
|
Технический лист |
AEE15W-M (15W) | 5-DIP Module, 4 Leads | Tube | Active | Isolated Module | 1 | 18V | 36V | 12V | - | - | - | 1.25A | 15 W | 4.2 kV | ITE (Commercial), Medical | OCP, OVP, SCP | -40°C ~ 80°C (With Derating) | 89% | - | - | Through Hole | 2.00" L x 1.00" W x 0.47" H (50.8mm x 25.4mm x 12.0mm) | - | - | - | - |
|
|
AEE01C48-MDC DC CONVERTER 15V 15W |
10 | - |
|
Технический лист |
AEE15W-M (15W) | 5-DIP Module, 4 Leads | Tube | Active | Isolated Module | 1 | 36V | 75V | 15V | - | - | - | 1A | 15 W | 4.2 kV | ITE (Commercial), Medical | OCP, OVP, SCP | -40°C ~ 80°C (With Derating) | 87% | - | - | Through Hole | 2.00" L x 1.00" W x 0.47" H (50.8mm x 25.4mm x 12.0mm) | - | - | - | - |
|
|
AEE01C24-MDC DC CONVERTER 15V 15W |
9 | - |
|
Технический лист |
AEE15W-M (15W) | 5-DIP Module, 4 Leads | Tube | Active | Isolated Module | 1 | 18V | 36V | 15V | - | - | - | 1A | 15 W | 4.2 kV | ITE (Commercial), Medical | OCP, OVP, SCP | -40°C ~ 80°C (With Derating) | 88% | - | - | Through Hole | 2.00" L x 1.00" W x 0.47" H (50.8mm x 25.4mm x 12.0mm) | - | - | - | - |
|
|
AEE01C12-MDC DC CONVERTER 15V 15W |
8 | - |
|
Технический лист |
AEE15W-M (15W) | 5-DIP Module, 4 Leads | Tube | Active | Isolated Module | 1 | 9V | 18V | 15V | - | - | - | 1A | 15 W | 4.2 kV | ITE (Commercial), Medical | OCP, OVP, SCP | -40°C ~ 80°C (With Derating) | 88% | - | - | Through Hole | 2.00" L x 1.00" W x 0.47" H (50.8mm x 25.4mm x 12.0mm) | - | - | - | - |
|
TES 3-4810WIDC DC CONVERTER 3.3V 2.5W |
30 | - |
|
Технический лист |
TES 3WI (3W) | 24-SMD Module, 12 Leads | Tube | Active | Isolated Module | 1 | 18V | 75V | 3.3V | - | - | - | 750mA | 2.5 W | 1.5 kV | ITE (Commercial) | Remote On/Off, SCP | -40°C ~ 71°C | 76% | - | - | Surface Mount | 1.27" L x 0.58" W x 0.40" H (32.2mm x 14.8mm x 10.2mm) | - | - | - | - |
|
TDR 3-2412WIDC DC CONVERTER 12V 3W |
44 | - |
|
Технический лист |
TDR 3WI (3W) | 14-DIP Module, 7 Leads | Tube | Active | Isolated Module | 1 | 9V | 36V | 12V | - | - | - | 250mA | 3 W | 1.6 kV | ITE (Commercial) | Remote On/Off, SCP | -40°C ~ 85°C | 82% | - | - | Through Hole | 0.74" L x 0.50" W x 0.34" H (18.9mm x 12.8mm x 8.7mm) | - | - | - | - |
|
TMR 6-7223WIRDC DC CONVERTER +/-15V 6W |
10 | - |
|
Технический лист |
TMR 6WIR (6W) | 8-SIP Module | Tube | Active | Isolated Module | 2 | 43V | 160V | 15V | -15V | - | - | 200mA, 200mA | 6 W | 3 kV | ITE (Commercial), Railway | Remote On/Off, OCP, SCP | -40°C ~ 80°C (With Derating) | 86% | - | - | Through Hole | 0.86" L x 0.38" W x 0.44" H (21.8mm x 9.6mm x 11.2mm) | - | - | - | - |
|
TDR 3-4811WIDC DC CONVERTER 5V 3W |
9 | - |
|
Технический лист |
TDR 3WI (3W) | 14-DIP Module, 7 Leads | Tube | Active | Isolated Module | 1 | 18V | 75V | 5V | - | - | - | 600mA | 3 W | 1.6 kV | ITE (Commercial) | Remote On/Off, SCP | -40°C ~ 85°C | 80% | - | - | Through Hole | 0.74" L x 0.50" W x 0.34" H (18.9mm x 12.8mm x 8.7mm) | - | - | - | - |
|
|
V48SD05024NNFHDC DC CONVERTER 5V 120W |
32 | - |
|
Технический лист |
V48SD (100W) | Sixteenth Brick | Tray | Active | Isolated Module | 1 | 36V | 60V | 5V | - | - | - | 24A | 120 W | 2.25 kV | ITE (Commercial) | Adjustable Output, PMBus™, Remote On/Off | -40°C ~ 85°C | 92.5% | - | - | Through Hole | 1.30" L x 0.90" W x 0.48" H (33.0mm x 22.9mm x 12.1mm) | Sixteenth Brick | Enable, Active Low | - | 62368-1 |
|
|
V48SD12010NNFHDC DC CONVERTER 12V 120W |
29 | - |
|
Технический лист |
V48SD (120W) | Sixteenth Brick | Tray | Active | Isolated Module | 1 | 36V | 60V | 12V | - | - | - | 10A | 120 W | 2.25 kV | ITE (Commercial) | Adjustable Output, Heat Sink, PMBus™, Remote On/Off | -40°C ~ 85°C | 93% | - | - | Through Hole | 1.30" L x 0.90" W x 0.48" H (33.0mm x 22.9mm x 12.1mm) | Sixteenth Brick | Enable, Active Low | - | 62368-1 |
|
THL 6-2422WISMDC DC CONVERTER +/-12V 6W |
23 | - |
|
Технический лист |
THL 6WISM (6W) | 16-SMD Module, 7 Leads | Tube | Not For New Designs | Isolated Module | 2 | 9V | 36V | 12V | -12V | - | - | 250mA, 250mA | 6 W | 1.5 kV | ITE (Commercial) | Remote On/Off, SCP | -40°C ~ 75°C (With Derating) | 83% | - | - | Surface Mount | 0.87" L x 0.80" W x 0.40" H (22.0mm x 20.3mm x 10.2mm) | - | - | - | - |
|
|
REM4A-1212S4W DC/DC-CONVERTER 'MEDLINE' DIP |
20 | - |
|
Технический лист |
REM4A (4W) | 16-DIP Module, 7 Leads | Tube | Active | Isolated Module | 1 | 9V | 18V | 12V | - | - | - | 292mA | 4 W | 5 kV | ITE (Commercial), Medical | Remote On/Off | -40°C ~ 105°C (With Derating) | 82% | - | - | Through Hole | 0.96" L x 0.57" W x 0.40" H (24.3mm x 14.4mm x 10.2mm) | - | Enable, Active High | cURus, UL | 60601-1; 62368-1 |
|
|
REM4A-1205S4W DC/DC-CONVERTER 'MEDLINE' DIP |
20 | - |
|
Технический лист |
REM4A (4W) | 16-DIP Module, 7 Leads | Tube | Active | Isolated Module | 1 | 9V | 18V | 5V | - | - | - | 700mA | 4 W | 5 kV | ITE (Commercial), Medical | Remote On/Off | -40°C ~ 105°C (With Derating) | 79% | - | - | Through Hole | 0.96" L x 0.57" W x 0.40" H (24.3mm x 14.4mm x 10.2mm) | - | Enable, Active High | cURus, UL | 60601-1; 62368-1 |
|
|
REM4A-0505S4W DC/DC-CONVERTER 'MEDLINE' DIP |
16 | - |
|
Технический лист |
REM4A (4W) | 16-DIP Module, 7 Leads | Tube | Active | Isolated Module | 1 | 4.5V | 12V | 5V | - | - | - | 700mA | 4 W | 5 kV | ITE (Commercial), Medical | Remote On/Off | -40°C ~ 105°C (With Derating) | 77% | - | - | Through Hole | 0.96" L x 0.57" W x 0.40" H (24.3mm x 14.4mm x 10.2mm) | - | Enable, Active High | cURus, UL | 60601-1; 62368-1 |
|
|
REM4A-0515S4W DC/DC-CONVERTER 'MEDLINE' DIP |
10 | - |
|
Технический лист |
REM4A (4W) | 16-DIP Module, 7 Leads | Tube | Active | Isolated Module | 1 | 4.5V | 12V | 15V | - | - | - | 234mA | 4 W | 5 kV | ITE (Commercial), Medical | Remote On/Off | -40°C ~ 105°C (With Derating) | 82% | - | - | Through Hole | 0.96" L x 0.57" W x 0.40" H (24.3mm x 14.4mm x 10.2mm) | - | Enable, Active High | cURus, UL | 60601-1; 62368-1 |
|
JHL0312S12DC DC CONVERTER 12V 3W |
10 | - |
|
Технический лист |
JHL (3W) | 24-DIP Module, 7 Leads | Tube | Active | Isolated Module | 1 | 10V | 17V | 12V | - | - | - | 250mA | 3 W | 4 kV | Medical | OCP, OVP, SCP, UVLO | -20°C ~ 80°C | 79% | - | - | Through Hole | 1.25" L x 0.80" W x 0.40" H (31.8mm x 20.3mm x 10.2mm) | - | - | - | - |
