Texas Instruments CD4093BE

< >

Сравнить

Номер детали:: CD4093BE

Производитель:: Texas Instruments

Категория:: Интегральные схемы (IC) в наличии

Упаковка:: 14-DIP (0.300", 7.62mm)

Технический лист:: CD4093BE.pdf

Описание:: IC GATE NAND 4CH 2-INP 14DIP

Количество:: Запрос цены Добавить в список RFQ Купить сейчас Добавить в корзину

Цена за единицу:$0

Общая цена:$0

Оплата:

Доставка:

Инвентарь:29,177

Отправьте нам ваш запрос, мы ответим сразу.

Наличие на складе:29,177

Кол-во	Цена за единицу	Общая цена
1+	$0.000	$0.000

Запрос цены Добавить в корзину

About CD4093BE

Looking for CD4093BE supplier or distributor? Tomato Electronics provides high-quality electronic components including MLCC capacitors, tantalum capacitors, ICs, diodes and more.

Подробности продукта

CD4093BE – TI CMOS Quad 2-Input NAND Schmitt Trigger

CD4093BE is a Texas Instruments CMOS logic IC that contains four independent 2-input NAND gates with Schmitt-trigger action on both inputs. With a 3V to 18V supply range, hysteresis input behavior and a 14-pin PDIP package, it is suitable for logic control, pulse shaping, noisy signal conditioning, oscillator circuits and simple timing designs.

Logic FunctionQuad 2-Input NAND

Input TypeSchmitt Trigger

Supply Range3V – 18V

Package14-Pin PDIP

Engineering note: Always verify the latest TI datasheet, logic thresholds, supply voltage, timing behavior and PCB-level noise conditions before final production approval.

Component Overview

CD4093BE belongs to the TI CD4093B CMOS logic family. Each of its four logic channels works as a 2-input NAND gate, while the Schmitt-trigger input structure helps improve switching behavior when the input signal is slow, noisy or not perfectly clean.

TomatoElec view: CD4093BE is useful when a design needs simple CMOS NAND logic together with improved noise tolerance. Its value comes from the combination of quad NAND functionality, Schmitt-trigger inputs, wide CMOS supply range and through-hole PDIP packaging for easy prototyping and maintenance.

Circuit Function & Design Role

NAND Logic Control

Provides four independent 2-input NAND gates for basic digital logic, enable control, interlock circuits and signal gating.

Schmitt-Trigger Input

Helps convert slow or noisy input signals into cleaner digital transitions with hysteresis behavior.

Pulse & Wave Shaping

Suitable for pulse shaping, edge cleanup and simple waveform conditioning in mixed analog-digital circuits.

Simple Timing Circuits

Often used in astable or monostable multivibrator circuits where RC timing and Schmitt-trigger switching are required.

Key Electrical & Package Information

Manufacturer	Texas Instruments
Part Number	CD4093BE
Logic Function	Quad 2-input NAND gate
Input Type	Schmitt-trigger inputs
Supply Voltage Range	3V to 18V
Number of Channels	4 channels
Package	14-pin PDIP / N package
Operating Temperature	-55°C to +125°C
Product Status	Active

Design reminder: Check supply voltage, input threshold behavior, output loading and unused input handling. In CMOS logic designs, unused inputs should not be left floating.

Application Scenarios

Logic Control Circuits

Used for basic NAND logic, signal gating, enable control and simple digital decision circuits.

Noisy Signal Conditioning

Schmitt-trigger inputs help clean up slow or noisy transitions from switches, sensors and RC networks.

Pulse Shaping

Suitable for wave shaping, pulse conditioning and digital edge restoration in control systems.

Oscillator & Timing Designs

Can be used with external RC networks for simple oscillator, monostable and astable timing functions.

TomatoElec Quality & Supply Notes

As an in-stock independent distributor and electronic components supplier, TomatoElec supports CD4093BE sourcing for maintenance, prototyping, production replenishment and BOM purchasing. For legacy CMOS logic ICs, correct part number, package type and manufacturer marking are important for stable circuit replacement.

Original component sourcing: support sourcing of original Texas Instruments logic ICs for customer BOM requirements.
Inventory support: help customers confirm available stock, package condition, date code and shipment schedule.
Package verification: confirm the 14-pin PDIP package before shipment, especially when comparing with SOIC or TSSOP variants.
BOM matching: verify supply voltage, logic family, package and temperature requirements before approving any substitute.

Replacement & BOM Matching Guidance

CD4093BE should not be replaced only by matching the "4093" logic function. Engineers should also compare supply voltage range, logic thresholds, Schmitt-trigger behavior, package, pinout, temperature range and manufacturer-specific parameters.

Selection tip: For customer BOM replacement, confirm whether the design requires a through-hole PDIP package or a surface-mount version. A functionally similar 4093 device may not be suitable if the package, pinout or threshold behavior does not match the original design.

FAQ

What is CD4093BE used for?

CD4093BE is used for NAND logic, noisy signal cleanup, pulse shaping, switch conditioning, oscillator circuits and simple timing designs.

What is the difference between a normal NAND gate and CD4093BE?

CD4093BE includes Schmitt-trigger inputs. This means it switches with hysteresis, which helps improve noise immunity and makes it suitable for slow or noisy input signals.

Is CD4093BE suitable for breadboard or maintenance use?

Yes. The 14-pin PDIP package is convenient for through-hole assembly, breadboard prototyping, repair work and older equipment maintenance.

Can TomatoElec support CD4093BE sourcing?

TomatoElec can support CD4093BE inquiry, inventory confirmation, BOM sourcing and shipment coordination. Customers are recommended to confirm required quantity, package type, date code preference and delivery schedule before ordering.

Final Selection Summary

CD4093BE is a practical CMOS logic IC for designs that need quad 2-input NAND gates with Schmitt-trigger inputs. Its main value is in logic control, noisy signal conditioning, pulse shaping, oscillator circuits and through-hole maintenance applications.

TomatoElec recommendation: Use CD4093BE when the BOM requires Texas Instruments CMOS logic, Schmitt-trigger NAND inputs, 3V to 18V operation and 14-pin PDIP packaging. Before production or replacement, verify package, pinout, supply voltage, input threshold behavior and system-level noise conditions.

CD4093BE Характеристики

Характеристики
Часто задаваемые вопросы
Статьи

Сравнение
Связанные

Изображения
Номер детали	CD4093BE
Производитель	Texas Instruments
	14-DIP (0.300", 7.62mm)
	Tube
	Active
	NAND Gate
	4
	2
	Schmitt Trigger
	3V ~ 18V
	4 µA
	3.4mA, 3.4mA
	0.9V ~ 4V
	3.6V ~ 10.8V
	130ns @ 15V, 50pF
	-55°C ~ 125°C
	-
	-
	Through Hole
	14-PDIP
