Texas Instruments TXS0104EDR

< >

Сравнить

Номер детали:: TXS0104EDR

Производитель:: Texas Instruments

Категория:: Интегральные схемы (IC) в наличии

Упаковка:

Технический лист:: TXS0104EDR.pdf

Описание:: IC TRANSLTR BIDIRECTIONAL 14SOIC

Количество:: Запрос цены Добавить в список RFQ Купить сейчас Добавить в корзину

Цена за единицу:$0

Общая цена:$0

Оплата:

Доставка:

Инвентарь:14,803

Отправьте нам ваш запрос, мы ответим сразу.

Наличие на складе:14,803

Кол-во	Цена за единицу	Общая цена
1+	$0.000	$0.000

Запрос цены Добавить в корзину

About TXS0104EDR

Looking for TXS0104EDR supplier or distributor? Tomato Electronics provides high-quality electronic components including MLCC capacitors, tantalum capacitors, ICs, diodes and more.

Подробности продукта

TXS0104EDR – TI 4-Bit Bidirectional Voltage-Level Translator

TXS0104EDR is a Texas Instruments 4-bit bidirectional voltage-level translator designed for open-drain and push-pull signal translation between different logic-voltage domains. With automatic direction sensing, no direction-control pin requirement, 1.65V to 3.6V A-port operation, 2.3V to 5.5V B-port operation and 14-pin SOIC package, it is suitable for GPIO, I2C, SMBus, SPI, UART, JTAG, MDIO, SDIO and mixed-voltage logic interfaces.

Function4-Bit Level Translator

DirectionAuto Bidirectional

Data Rate24Mbps Push-Pull

PackageD / SOIC-14

Engineering note: Verify the latest TI datasheet, VCCA/VCCB relationship, pull-up resistor values, bus capacitance, open-drain speed limit, edge-rate behavior and PCB routing before production approval.

Component Overview

TXS0104EDR belongs to the TI TXS0104E family of 4-bit bidirectional voltage-level translators. It enables logic-level translation between a lower-voltage A port and a higher-voltage B port without requiring a dedicated direction-control signal.

TomatoElec view: TXS0104EDR is useful when a design needs compact 4-channel level shifting between processors, sensors, memory cards and peripheral interfaces. Its value comes from automatic bidirectional translation, open-drain and push-pull support, low-voltage A-port compatibility and standard SOIC-14 packaging.

Circuit Function & Design Role

Mixed-Voltage Translation

Translates signals between low-voltage logic domains such as 1.8V or 3.3V and higher 3.3V or 5V rails.

Automatic Direction Control

Supports bidirectional signal flow without a separate DIR control pin, simplifying interface routing.

Open-Drain Bus Support

Suitable for I2C, SMBus and similar open-drain interfaces when pull-up and bus-capacitance limits are validated.

Push-Pull Interface Support

Can be used for GPIO, SPI, UART and other push-pull logic signals within the supported operating range.

Key Electrical & Package Information

Manufacturer	Texas Instruments
Part Number	TXS0104EDR
Device Type	4-bit bidirectional voltage-level translator
Topology	Open-drain and push-pull level translation
Direction Control	Automatic direction sensing
A-Port Voltage Range	1.65V to 3.6V
B-Port Voltage Range	2.3V to 5.5V
Supply Condition	VCCA ≤ VCCB
Maximum Data Rate	24Mbps push-pull; 2Mbps open-drain
Features	Output enable, edge-rate accelerator, no power-supply sequencing requirement
Common Applications	GPIO, I2C, JTAG, MDIO, SDIO, SMBus, SPI, UART
Package	D / 14-pin SOIC
Carrier	Large tape and reel
Operating Temperature	-40°C to +85°C
Product Status	Active

Design reminder: Auto-bidirectional level translators are sensitive to pull-up strength, trace capacitance, signal edge rate and bus loading. Validate the real interface under worst-case voltage and temperature conditions.

Application Scenarios

I2C / SMBus Translation

Used to connect controllers, sensors and peripheral devices operating at different logic voltages.

Processor Peripheral Interfaces

Suitable for GPIO, SPI, UART, JTAG, MDIO and SDIO level shifting between processors and external devices.

Portable Electronics

Applicable to compact systems where low-voltage ICs must communicate with 3.3V or 5V peripherals.

Industrial Control Boards

Useful for mixed-voltage digital communication between control ICs, sensors, interface chips and modules.

TomatoElec Quality & Supply Notes

As an in-stock independent distributor and electronic components supplier, TomatoElec supports TXS0104EDR sourcing for engineering samples, production replenishment, urgent replacement and BOM purchasing. For voltage translators, correct orderable part number, package type, reel condition, date code and original sourcing are important because the device affects interface stability, logic timing and long-term system reliability.

Original component sourcing: support sourcing of original Texas Instruments logic and voltage translation ICs.
Inventory support: help confirm available stock, package condition, date code and shipment schedule.
Package verification: confirm D / SOIC-14 package and tape-and-reel carrier before shipment.
BOM matching: verify channel count, voltage range, interface type, package, pinout and temperature requirements before approving any substitute.

Replacement & BOM Matching Guidance

TXS0104EDR should not be replaced only by matching the 4-bit level-shifter category. Engineers should compare A-port and B-port voltage ranges, auto-direction behavior, open-drain compatibility, push-pull data rate, output enable behavior, package, pinout, pull-up requirements and temperature rating.

Selection tip: TXS and TXB translators are not always interchangeable. If the interface has pull-ups, strong external drivers, long traces or large capacitive loading, review the TI design guidance before approving a substitute.

FAQ

What is TXS0104EDR used for?

It is used for 4-bit bidirectional voltage-level translation in GPIO, I2C, SMBus, SPI, UART, JTAG, MDIO, SDIO and mixed-voltage digital interfaces.

Does TXS0104EDR need a direction-control signal?

No. TXS0104EDR supports automatic bidirectional level translation and does not require a separate direction-control signal.

What package is TXS0104EDR?

TXS0104EDR uses the D package, which is a 14-pin SOIC package supplied in large tape-and-reel format.

Can TomatoElec support TXS0104EDR sourcing?

TomatoElec can support TXS0104EDR inquiry, inventory confirmation, BOM sourcing and shipment coordination.

Final Selection Summary

TXS0104EDR is a compact 4-bit auto-bidirectional voltage-level translator for designs requiring open-drain and push-pull signal translation, mixed-voltage logic support and SOIC-14 packaging.

TomatoElec recommendation: Use TXS0104EDR when the BOM requires Texas Instruments TXS-series 4-bit bidirectional level translation, A-port low-voltage support, B-port 5V compatibility and D / SOIC-14 packaging.

TXS0104EDR Характеристики

Характеристики
Часто задаваемые вопросы
Статьи

Сравнение
Связанные

Изображения
Номер детали	TXS0104EDR
Производитель	Texas Instruments

	Tape & Reel (TR)
	Active
	Voltage Level
	Bidirectional
	1
	4
	1.65 V ~ 3.6 V
	2.3 V ~ 5.5 V
	-
	-
	Open Drain, Push-Pull
	24Mbps
	-40°C ~ 85°C (TA)
	-
	-
	Auto-Direction Sensing
	Surface Mount
	14-SOIC (0.154", 3.90mm Width)
